| ブランド名: | SANROCK POWER |
| モデル番号: | SPDG20KW |
| MOQ: | 1セット |
| 価格: | Chat with supplier now for more details. |
| パッケージの詳細: | 機械用のヌードパッケージ、スペアパーツ用の木製ボックスパッケージ、または顧客の需要。 |
| 支払条件: | マネーグラム、ウェスタンユニオン、T/T、D/P、D/A、L/C |
Durability: The exposed steel frame offers superior protection for the core components and simplifies maintenance and repairs.
Portability: Most models are mounted on a wheel kit (trailer), making them relatively easy to move around a worksite or transport between locations.
In summary, a 20KW open-frame generator is a workhorse solution best suited for demanding environments where cost-effectiveness, durability, and easy serviceability are more important than quiet operation.
Industrial and Manufacturing
Backup Power for SMEs: Acts as an emergency power supply for small to medium-sized workshops, factories, and warehouses to prevent production stoppages and protect machinery during power cuts.
Primary Power for Remote Sites: Serves as the main power source for remote industrial operations like mining camps, forestry operations, and quarry sites.
Applicable Industries
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant,
Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company.
Product descriptions from the supplier
100KVA 150KVA 200KVA 300KVA 400KVA 500KVA 700KVA Diesel Genset
"Contact us for specific product details or customized requirements"
Product Description
| Technical parameters of diesel generator set Generator set model:SPDG20KW Steady state voltage adjustment rate (%):≤± 1 Generator power:20kW/25kVA Voltage fluctuation rate (%):≤ ± 0.5 Power factor:COSΦ = 0.8 (lagging) Transient voltage adjustment rate (%):＋20 ～－15 Output voltage:400V/230V Voltage stabilization time (s):≤1 Generator set current:36A Steady state frequency adjustment rate (%):≤ ± 1 Rated frequency:50Hz Frequency fluctuation rate (%):≤ ± 0.5 Rated speed:1500rpm Transient frequency adjustment rate (%):+ 10 ~ -7 Fuel grade:(standard) 0 # light diesel (normal temperature) Frequency stabilization time (S):≤3 Diesel generator size:1620*620*1380(L*W*H mm Diesel generator fuel consumption (100% load):224g/kW·h Diesel generator weight:600kg Diesel generator volume(LP7m):95dB(A) Technical parameters of diesel engine Cooling method: Closed water-cooling Oil supply method: direct injection Engine cylinder number: 4 / L Type Speed regulation method: Mechanical Bore stroke: 102*120mm Intake method: Natural inhalation Compression ratio: 16.5:1 Overload capacity: 110% Start method:DC 24V Electric start Diesel engines Speed: 1500rpm Technical parameters of generator Protection level:IP22 Wiring mode:Three-phase four-wire, Y-connection Generator power: 20kW/25kVA Adjustment method: AVR (Automatic Voltage Regulator) Rated voltage: 400V / 230V Output frequency: 50Hz Insulation class: H class Output factor: COSΦ = 0.8 (lag) |
Customizable Options: SANROCK POWER Machinery Co., Ltd., offers various customization options for their products, including different genset power and frequency settings. This flexibility allows users to select the most appropriate equipment for their specific requirements, ensuring optimal performance and energy efficiency.
SANROCK POWER Machinery is committed to offering competitive prices without compromising on quality. Their products come with a 3-year warranty period, which provides customers with the assurance and peace of mind necessary to confidently purchase and utilize their generators.
FAQ
1. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;
2.what can you buy from us?
Screw Air Compressor,Reefer Container Generator,Diesel Generator,Light Tower,Sewage Pump,Centrifugal Pump,Fire Pump System,Mobile Pump Truck
3. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,Express Delivery；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,Western Union,Cash;
Language Spoken:English,Chinese,Spanish
|
